AT-S60 Management Software User’s Guide
Section V: Security Features 573
When you configure a port with a Supplicant role, the Status field
can have the following values:
Acquired
Authenticated
Authenticating
Connecting
Disconnected
Held
Logoff
Note
Consult IEEE std 8021X-2001 for Port-Based Network Access Control
for detailed information regarding the above mentioned values in
the Status field.
Additional Info - When you assign a port the role of
Authenticator and it has a status of Authenticated, this field also
displays the MAC address of the Authenticator.
Displaying
Authenticator
Ports
To display information about authenticator ports and parameters,
perform the following procedure:
1. From the Main Menu, type 6 to select Security Menu.
The Security Menu is shown in Figure 151 on page 473.
2. From the Security Menu, select Port Access Control.
The Port Access Control Menu is shown in Figure 180 on page 557.
3. From the Port Access Control Menu, type 4 to select Configure
Authenticator.
The Configure Authenticator menu is shown in Figure 182 on
page 562.
4. Type 2 to select Display Authenticator Port Access Parameters.
