Chapter 14: IGMP Snooping
Section II: Advanced Features 226
Displaying a List of Multicast Routers
A multicast router is a router that is receiving multicast packets from a
multicast application and transmitting the packets to host nodes. You
can use the AT-S60 software to display a list of the multicast routers that
are connected to the switch.
To display a list of the multicast routers, perform the following
procedure:
1. From the IGMP Snooping Configuration Menu, type 7 to select View
Multicast Router List.
For instructions on how to display the IGMP Snooping
Configuration menu, perform Steps 1 to 4 of Configuring IGMP
Snooping on page 221.
The View Multicast Routers List Menu is displayed. The
appearance of the menu differs depending on whether the ports
connected to multicast routers are determined automatically or
manually. Figure 69 is an example of how the menu looks if the
multicast router ports are being determined automatically.
Figure 69 View Multicast Routers List Menu
The information in this menu is for viewing purposes only. The
columns are defined below:
VLAN ID
The VID of the VLAN where the port is an untagged member.
Port/TrunkId
This column displays router members present on either a port or
a trunk of the switch.
Allied Telesyn AT-8400 Series - ATS60 V2.1.0
Engineering Switch 142
User: Manager 00:14:33 01-Jan-2004
View Multicast Routers List
=======================================================
VLAN ID
Port/TrunkId RouterIP
=======================================================
1
-/1 172.16.01.1
2 8.1-8/- 172.16.25.9
14 -/25 172.16.35.7
U - Update Display
R - Return to Previous Menu
Enter your selection?
