Chapter 20: GARP VLAN Registration Protocol

Section IV: VLANs

450

The architecture of GARP is shown in Figure 138.

Figure 138 GARP Architecture

The GARP Application component of the GARP Participant is responsible
for defining the semantics associated with the parameter values and
operators received in GARP PDUs, and for generating GARP PDUs for
transmission. The Application makes use of the GID component, and the
state machines associated with the operation of GID, in order to control
its protocol interactions.

Switch

GARP Application

GID

GARP PDU

s

GARP PDU

s

MAC Layer:
Port 1

LLC

GARP Participant

GARP Application

GID

GARP PDU

s

GARP PDU

s

MAC Layer:
Port 2

LLC

GARP Participant

GIP
