AT-S60 Management Software User’s Guide
Section II: Advanced Features 245
Configuring STP
Port Parameters
To adjust a port’s STP parameters, perform the following procedure:
1. From the Main Menu, type 3 to select Spanning Tree Menu.
The Spanning Tree Menu is shown in Figure 74 on page 240.
2. From the Spanning Tree Menu, type 3 to select STP Configuration.
The STP Menu is shown in Figure 75 on page 243.
3. From the STP Menu, type P to select STP Port Parameters.
The STP Port Parameters Menu is shown in Figure 76.
Figure 76 STP Port Parameters Menu
4. Type 1 to select Configure STP Port Settings.
The following prompt is displayed:
Enter port-list:
5. Enter the port to configure. For instructions on how to specify port
numbers, refer to Specifying Ports on page 34.
Allied Telesyn AT-8400 Series - ATS60 V2.1.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2004
STP Port Parameters
1 - Configure STP Port Settings
2 - Display STP Port Configuration
R - Return to Previous Menu
Enter your selection?
