AT-S60 Management Software User’s Guide
Section VI: Web Browser Management 779
The information on this page is described in Table 19.
Displaying
GVRP State
Machine
To display the GVRP State Machine for each VLAN ID, perform the
following procedures.
1. From the Home Page, select Monitoring.
The Monitoring System Page is displayed with the General Tab
selected by default, as shown in Figure 194 on page 592.
2. Select the Layer 2 option.
The Monitoring Layer 2 Page is displayed with the MAC Address
Tab selected by default, as shown Figure 212 on page 634.
3. Select the GVRP Tab.
The GVRP Tab is shown in Figure 283 on page 772.
4. To display the GVRP State Machine, click the circle next to View GVRP
State Machine for VLAN in the View GVRP Parameters section of the
page.
5. Enter the VLAN ID in the box next to View GVRP State Machine for
VLAN. Then click View.
Table 19 GIP Connected Ports Ring Parameters
Parameter Meaning
GARP Application Identifies the GARP application, that is,
“GVRP.”
GIP Context ID A number assigned to the instance for the
GIP context.
STP ID Present if the GARP application is GVRP;
identifies the STP that has these ports
connected in the GIP connected ring.
Ring Ring of connected ports. Only ports
presently in the STP Forwarding state are
eligible for membership to the GIP
connected ring. If no ports exist in the GIP
connected ring, “No ports are connected” is
displayed. If the GARP application has no
ports, “No ports have been assigned” is
displayed.
