AT-S60 Management Software User’s Guide
Section II: Advanced Features 247
Displaying STP
Port Settings
To display port STP settings, perform the following procedure:
1. From the Spanning Tree Menu, type 3 to select STP Configuration.
The STP Menu is shown in Figure 75 on page 243.
2. From the STP Menu, type P to select STP Port Parameters.
The STP Port Parameters Menu is shown in Figure 76 on page 245.
3. From the STP Port Parameters Menu, type 2 to select Display STP Port
Configuration.
The Display STP Port Configuration Menu is shown in Figure 78.
Figure 78 Display STP Port Configuration Menu
Allied Telesyn AT-8400 Series - ATS60 V2.1.0
High School Switch 142
User: Manager 00:14:33 15-Jan-2004
Display STP Port Configuration
Port State Cost Priority
----------------------------------------------
1.1 Disabled Auto-Update 128
1.2 Disabled Auto-Update 128
1.3 Disabled Auto-Update 128
1.4 Disabled Auto-Update 128
1.5 Disabled Auto-Update 128
1.6 Disabled Auto-Update 128
1.7 Disabled Auto-Update 128
1.8 Disabled Auto-Update 128
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
