AT-S60 Management Software User’s Guide
Section VI: Web Browser Management 611
3. In the Server IP Address field, enter the IP address of the network node
that contains the TFTP server software.
4. In the Operation field, click Download.
5. In the Server Filename field, enter the name of the file that resides on
the TFTP server.
This file is downloaded to the switch.
6. In the Local Filename field, enter a name for the file.
This is the filename that appears on the switch. If you are
downloading the AT-S60 image file, enter “ats60.img” as the
filename.
7. In the File Type, select one of the following:
❑ Image - Select this option if you are downloading the AT-S60
image file.
❑ Default Config - Select this option if you are downloading a
configuration file and you want the file to be designated as the
active boot configuration file.
❑ General - Select this option if you are downloading a CA certificate
or encryption key, or a configuration file that you do not want
designated as the active boot configuration file.
8. Click Apply.
The management software will notify you once the download is
complete.
Caution
Once you download an AT-S60 switch image file, the switch writes it
to flash. During this process, do not reset or power off the unit. Then
you must restart the switch in order to load the new image. To
continue managing the switch via the Web, you must reestablish
the management session.
