Chapter 15: STP and RSTP
Section II: Advanced Features 256
The Display RSTP Port State Menu is shown in Figure 78.
Figure 83 Display RSTP Port State
This selection displays a menu that contains the following RSTP
operating status for a port:
❑ State - Identifies the RSTP state of the port. The states are:
disabled, discarding, learning, and forwarding. A state of disabled
means the port has not established a link with its end node or the
link is down.
❑ Role - Indicates the RSTP role of the port. The role are root,
alternate, backup, and designated.
❑ P2P - Indicates whether the port is a point-to-point port. The
values are yes, no, and auto-detect.
❑ Version - Indicates whether the port is operating in RSTP mode,
STP-compatible mode, or MSTP mode. The values are rstp, stp, or
mstp.
❑ Port-Cost - Indicates the port cost of the port.
Allied Telesyn AT-8400 Series - ATS60 V2.1.0
Production Switch 142
User: Manager 00:14:33 15-Mar-2004
Display RSTP Port State
Port State Role P2P Version Port-Cost
-------------------------------------------------------------------
1.1 Disabled -------------------------------------
3.1 Disabled -------------------------------------
3.2 Disabled -------------------------------------
3.3 Disabled -------------------------------------
3.4 Forwarding Designated Yes RSTP 200000
3.5 Disabled -------------------------------------
3.6 Disabled -------------------------------------
3.7 Disabled -------------------------------------
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
