920 Brocade 6910 Ethernet Access Switch Configuration Guide
53-1002651-02
42
Configuring 802.1X Port Authentication
Interface
To display port authenticator statistics for 802.1X:
1. Click Security, Port Authentication.
2. Select Show Statistics from the Step list.
3. Click Authenticator.
FIGURE 230 Showing Statistics for 802.1X Port Authenticator
To display port supplicant statistics for 802.1X:
1. Click Security, Port Authentication.
2. Select Show Statistics from the Step list.
Rx EAP Resp/Id The number of EAP Resp/Id frames that have been received by this
Supplicant.
Rx EAP Resp/Oth The number of valid EAP Response frames (other than Resp/Id
frames) that have been received by this Supplicant.
Rx EAP LenError The number of EAPOL frames that have been received by this
Supplicant in which the Packet Body Length field is invalid.
Tx EAPOL Total The number of EAPOL frames of any type that have been transmitted
by this Supplicant.
Tx EAPOL Start The number of EAPOL Start frames that have been transmitted by
this Supplicant.
Tx EAPOL Logoff The number of EAPOL Logoff frames that have been transmitted by
this Supplicant.
Tx EAP Req/Id The number of EAP Req/Id frames that have been transmitted by
this Supplicant.
Tx EAP Req/Oth The number of EAP Request frames (other than Rq/Id frames) that
have been transmitted by this Supplicant.
TABLE 171 802.1X Statistics (Continued)
Parameter Description
