Brocade 6910 Ethernet Access Switch Configuration Guide

293

53-1002651-02

13

Link Aggregation Commands

Console(config-if)#

Trunk Status Display Commands

show lacp

This command displays LACP information.

Syntax

show lacp [port-channel] {counters | internal | neighbors | sys-id}

port-channel - Local identifier for a link aggregation group. (Range: 1-12)

counters - Statistics for LACP protocol messages.

internal - Configuration settings and operational state for local side.

neighbors - Configuration settings and operational state for remote side.

sys-id - Summary of system priority and MAC address for all channel groups.

Default Setting
Port Channel: all

Command Mode
Privileged Exec

Example

Console#show lacp 1 counters

Port Channel: 1

-------------------------------------------------------------------------

Eth 1/ 2

-------------------------------------------------------------------------

LACPDUs Sent : 12

LACPDUs Received : 6

Marker Sent : 0

Marker Received : 0

LACPDUs Unknown Pkts : 0

LACPDUs Illegal Pkts : 0

.

.

.

TABLE 66

show lacp counters - display description

Field

Description

LACPDUs Sent

Number of valid LACPDUs transmitted from this channel group.

LACPDUs Received

Number of valid LACPDUs received on this channel group.

Marker Sent

Number of valid Marker PDUs transmitted from this channel group.

Marker Received

Number of valid Marker PDUs received by this channel group.

LACPDUs Unknown
Pkts

Number of frames received that either (1) Carry the Slow Protocols Ethernet Type value, but
contain an unknown PDU, or (2) are addressed to the Slow Protocols group MAC Address,
but do not carry the Slow Protocols Ethernet Type.

LACPDUs Illegal
Pkts

Number of frames that carry the Slow Protocols Ethernet Type value, but contain a badly
formed PDU or an illegal value of Protocol Subtype.
