Brocade 6910 Ethernet Access Switch Configuration Guide 479
53-1002651-02
23
MVR for IPv4
Example
The following statically assigns a multicast group to a receiver port:
Console(config)#interface ethernet 1/7
Console(config-if)#mvr domain 1 type receiver
Console(config-if)#mvr domain 1 vlan 3 group 225.0.0.5
Console(config-if)#
show mvr
This command shows information about MVR domain settings, including MVR operational status,
the multicast VLAN, the current number of group addresses, and the upstream source IP address.
Syntax
show mvr [domain domain-id]
domain-id - An independent multicast domain. (Range: 1-5)
Default Setting
Displays configuration settings for all MVR domains.
Command Mode
Privileged Exec
Example
The following shows the MVR settings:
Console#show mvr
MVR 802.1p Forwarding Priority : Disabled
MVR Proxy Switching : Enabled
MVR Robustness Value : 1
MVR Domain : 1
MVR Config Status : Enabled
MVR Running Status : Active
MVR Multicast VLAN : 1
MVR Current Learned Groups : 10
MVR Upstream Source IP : 192.168.0.3
.
.
.
TABLE 111 show mvr - display description
Field Description
MVR 802.1p Forwarding
Priority Priority assigned to multicast traffic forwarded into the MVR VLAN
MVR Proxy Switching Shows if MVR proxy switching is enabled
MVR Robustness Value Shows the number of reports or query messages sent when proxy switching is
enabled
MVR Domain An independent multicast domain.
MVR Config Status Shows if MVR is globally enabled on the switch.
MVR Running Status Indicates whether or not all necessary conditions in the MVR environment are
satisfied. (Running status is true as long as MVR Status is enabled, and the
specified MVR VLAN exists.)
