Page 483: Chapter
Brocade 6910 Ethernet Access Switch Configuration Guide
427
53-1002651-02
Chapter
22
Quality of Service Commands
In this chapter
The commands described in this chapter are used to configure Differentiated Services (DiffServ)
classification criteria and service policies. You can classify traffic based on access lists, IP
Precedence or DSCP values, or VLANs. Using access lists allows you select traffic based on Layer 2,
Layer 3, or Layer 4 information contained in each packet.
TABLE 102
Quality of Service Commands
Command
Function
Mode
Creates a class map for a type of traffic
GC
Specifies the description of a class map
CM
Defines the criteria used to classify traffic
CM
Redefines the name of a class map
CM
Creates a policy map for multiple interfaces
GC
Specifies the description of a policy map
PM
Defines a traffic classification for the policy to act on
PM
Redefines the name of a policy map
PM
Defines an enforcer for classified traffic based on a metered flow rate
PM-C
Defines an enforcer for classified traffic based on a single rate three
color meter
PM-C
Defines an enforcer for classified traffic based on a two rate three color
meter
PM-C
Services IP traffic by setting a class of service value for matching
packets for internal processing
PM-C
Services IP traffic by setting a IP DSCP value for matching packets for
internal processing
PM-C
Services IP traffic by setting a per-hop behavior value for matching
packets for internal processing
PM-C
Applies a policy map defined by the
command to a
particular interface
IC
Displays the QoS class maps which define matching criteria used for
classifying traffic
PE
Displays the QoS policy maps which define classification criteria for
incoming traffic, and may include policers for bandwidth limitations
PE
Displays the configuration of all classes configured for all service
policies on the specified interface
PE
