Brocade 6910 Ethernet Access Switch Configuration Guide
1125
53-1002651-02
47
Multicast VLAN Registration for IPv4
•
Leave – The number of leave messages received on this interface.
•
G Query – The number of general query messages received on this interface.
•
G(-S)-S Query – The number of group specific or group-and-source specific query messages
received on this interface.
•
Drop – The number of times a report, leave or query was dropped. Packets may be dropped
due to invalid format, rate limiting, packet content not allowed, or MVR group report received.
•
Join Success – The number of times a multicast group was successfully joined.
•
Group – The number of MVR groups active on this interface.
Output Statistics
•
Report – The number of IGMP membership reports sent from this interface.
•
Leave – The number of leave messages sent from this interface.
•
G Query – The number of general query messages sent from this interface.
•
G(-S)-S Query – The number of group specific or group-and-source specific query messages
sent from this interface.
Interface
To display statistics for MVR query-related messages:
1. Click Multicast, MVR.
2. Select Show Statistics from the Step list.
3. Select Show Query Statistics from the Action list.
4. Select an MVR domain.
FIGURE 400
Displaying MVR Statistics – Query
