726

Brocade 6910 Ethernet Access Switch Configuration Guide

53-1002651-02

34

Trunk Configuration

Configuring a Static Trunk

Use the Interface > Trunk > Static page to create a trunk, assign member ports, and configure the
connection parameters.

FIGURE 55

Configuring Static Trunks

CLI References

“Link Aggregation Commands”

on page 285

“Interface Commands”

on page 255

Command Usage

When configuring static trunks, you may not be able to link switches of different types,
depending on the vendor’s implementation.

To avoid creating a loop in the network, be sure you add a static trunk via the configuration
interface before connecting the ports, and also disconnect the ports before removing a static
trunk via the configuration interface.

Parameters
These parameters are displayed:

Trunk ID – Trunk identifier. (Range: 1-12)

Member – The initial trunk member. Use the Add Member page to configure additional
members.

Unit – Unit identifier. (Range: 1)

Port – Port identifier. (Range: 1-12)

Interface
To create a static trunk:

1. Click Interface, Trunk, Static.

2. Select Configure Trunk from the Step list.

3. Select Add from the Action list.

4. Enter a trunk identifier.

5. Set the unit and port for the initial trunk member.

6. Click Apply.

active
links

}

statically
configured
