Configuring Protocol-based VLANs
show traffic-segmentation
This command displays the configured traffic segments.
Command Mode
Privileged Exec
Example
Console#show traffic-segmentation
Private VLAN Status : Enabled
Uplink-to-Uplink Mode : Forwarding
Session Uplink Ports Downlink Ports
--------- ------------------------------ -----------------------------
1 Ethernet 1/1 Ethernet 1/2
Ethernet 1/3
Ethernet 1/4
Console#
Configuring Protocol-based VLANs
The network devices required to support multiple protocols cannot be easily grouped into a
common VLAN. This may require non-standard devices to pass traffic between different VLANs in
order to encompass all the devices participating in a specific protocol. This kind of configuration
deprives users of the basic benefits of VLANs, including security and easy accessibility.
To avoid these problems, you can configure this switch with protocol-based VLANs that divide the
physical network into logical VLAN groups for each required protocol. When a frame is received at a
port, its VLAN membership can then be determined based on the protocol type in use by the
inbound packets.
To configure protocol-based VLANs, follow these steps:
1. First configure VLAN groups for the protocols you want to use (see
Although not mandatory, we suggest configuring a separate VLAN for each major protocol
running on your network. Do not add port members at this time.
2. Create a protocol group for each of the protocols you want to assign to a VLAN using the
command (Global Configuration mode).
3. Then map the protocol for each interface to the appropriate VLAN using the
command (Interface Configuration mode).
TABLE 92
Protocol-based VLAN Commands
Command
Function
Mode
Create a protocol group, specifying the supported protocols
GC
Maps a protocol group to a VLAN
IC
show protocol-vlan protocol-group
Shows the configuration of protocol groups
PE
show interfaces protocol-vlan
protocol-group
Shows the interfaces mapped to a protocol group and the
corresponding VLAN
PE
