694

Brocade 6910 Ethernet Access Switch Configuration Guide

53-1002651-02

33

Configuring Telnet Settings

Interface
To configure parameters for the console port:

1. Click System, then Console.

2. Specify the connection parameters as required.

3. Click Apply

FIGURE 24

Console Port Settings

Configuring Telnet Settings

Use the System > Telnet menu to configure parameters for accessing the CLI over a Telnet
connection. You can access the onboard configuration program over the network using Telnet (i.e.,
a virtual terminal). Management access via Telnet can be enabled/disabled and other parameters
set, including the TCP port number, time outs, and a password. Note that the password is only
configurable through the CLI.) These parameters can be configured via the web or CLI interface.

CLI References

“Line”

on page 75

“Telnet Server”

on page 162

Parameters
The following parameters are displayed:

Telnet Status – Enables or disables Telnet access to the switch. (Default: Enabled)

TCP Port – Sets the TCP port number for Telnet on the switch. (Default: 23)

Max Sessions – Sets the maximum number of Telnet sessions that can simultaneously
connect to this system. (Range: 0-8)
A maximum of eight sessions can be concurrently opened for Telnet and Secure Shell (i.e.,
both Telnet and SSH share a maximum number or eight sessions).

Login Timeout – Sets the interval that the system waits for a user to log into the CLI. If a login
attempt is not detected within the timeout interval, the connection is terminated for the
session. (Range: 10-300 seconds; Default: 300 seconds)
