Brocade 6910 Ethernet Access Switch Configuration Guide 481
53-1002651-02
23
MVR for IPv4
Example
The following displays information about the interfaces attached to the MVR VLAN in domain 1:
Console#show mvr domain 1 interface
MVR Domain : 1
Port Type Status Immediate Static Group Address
-------- -------- ------------------- --------- -------------------------
Eth 1/ 1 Source Active/Forwarding
Eth 1/ 2 Receiver Inactive/Discarding Disabled 234.5.6.8(VLAN2)
Eth1/ 3 Source Inactive/Discarding
Eth1/ 1 Receiver Active/Forwarding Disabled 225.0.0.1(VLAN1)
225.0.0.9(VLAN3)
Eth1/ 4 Receiver Active/Discarding Disabled
Console#
show mvr members
This command shows information about the current number of entries in the forwarding database,
detailed information about a specific multicast address, the IP address of the hosts subscribing to
all active multicast groups, or the multicast groups associated with each port.
Syntax
show mvr [domain domain-id] members [ip-address |
host-ip-address [interface] | sort-by-port [interface]]]
domain-id - An independent multicast domain. (Range: 1-5)
ip-address - IPv4 address for an MVR multicast group.
(Range: 224.0.1.0 - 239.255.255.255)
members - The multicast groups assigned to the MVR VLAN.
host-ip-address - The subscriber IP addresses.
sort-by-port - The multicast groups associated with an interface.
interface
ethernet unit/port
unit - Unit identifier. (Range: 1)
port - Port number. (Range: 1-12)
port-channel channel-id (Range: 1-12)
TABLE 112 show mvr interface - display description
Field Description
Port Shows interfaces attached to the MVR.
Type Shows the MVR port type.
Status Shows the MVR status and interface status. MVR status for source ports is
“ACTIVE” if MVR is globally enabled on the switch. MVR status for receiver ports is
“ACTIVE” only if there are subscribers receiving multicast traffic from one of the
MVR groups, or a multicast group has been statically assigned to an interface. Also
shows if MVR traffic is being forwarded or discarded.
Immediate Shows if immediate leave is enabled or disabled.
Static Group Address Shows any static MVR group assigned to an interface, and the receiver VLAN.
