Brocade 6910 Ethernet Access Switch Configuration Guide
735
53-1002651-02
34
Trunk Configuration
Interface
To display LACP settings and status for the local side:
1. Click Interface, Trunk, Dynamic.
2. Select Configure Aggregation Port from the Step list.
3. Select Show Information from the Action list.
4. Click Internal.
5. Select a group member from the Port list.
Admin State,
Oper State
Administrative or operational values of the actor’s state parameters:
◆
Expired – The actor’s receive machine is in the expired state;
◆
Defaulted – The actor’s receive machine is using defaulted
operational partner information, administratively configured for
the partner.
◆
Distributing – If false, distribution of outgoing frames on this link
is disabled; i.e., distribution is currently disabled and is not
expected to be enabled in the absence of administrative changes
or changes in received protocol information.
◆
Collecting – Collection of incoming frames on this link is enabled;
i.e., collection is currently enabled and is not expected to be
disabled in the absence of administrative changes or changes in
received protocol information.
◆
Synchronization – The System considers this link to be IN_SYNC;
i.e., it has been allocated to the correct Link Aggregation Group,
the group has been associated with a compatible Aggregator, and
the identity of the Link Aggregation Group is consistent with the
System ID and operational Key information transmitted.
◆
Aggregation – The system considers this link to be aggregatable;
i.e., a potential candidate for aggregation.
◆
Long timeout – Periodic transmission of LACPDUs uses a slow
transmission rate.
◆
LACP-Activity – Activity control value with regard to this link.
(0: Passive; 1: Active)
TABLE 157
LACP Internal Configuration Information (Continued)
Parameter
Description
