Brocade 6910 Ethernet Access Switch Configuration Guide 669
53-1002651-02
32
Navigating the Web Browser Interface
ERPS Ethernet Ring Protection Switching 982
Configure Global Activates ERPS globally 984
Configure Domain 985
Add Creates an ERPS ring 985
Show Shows list of configured ERPS rings, status, and settings 985
Configure Details Configures ring parameters 985
CFM Connectivity Fault Management 992
Configure Global Configures global settings, including administrative status, cross-check
start delay, link trace, and SNMP traps 995
Configure Interface Configures administrative status on an interface 998
Configure MD Configure Maintenance Domains 999
Add Defines a portion of the network for which connectivity faults can
be managed, identified by an MD index, maintenance level, and the MIP
creation method 999
Configure Details Configures the archive hold time and fault notification settings 999
Show Shows list of configured maintenance domains 999
Configure MA Configure Maintenance Associations 1003
Add Defines a unique CFM service instance, identified by its parent MD, the
MA index, the VLAN assigned to the MA, and the MIP creation method 1003
Configure Details Configures detailed settings, including continuity check status and
interval level, cross-check status, and alarm indication signal parameters 1003
Show Shows list of configured maintenance associations 1003
Configure MEP Configures Maintenance End Points 1007
Add Configures MEPs at the domain boundary to provide management access
for each maintenance association 1007
Show Shows list of configured maintenance end points 1007
Configure Remote MEP Configures Remote Maintenance End Points 1008
Add Configures a static list of remote MEPs for comparison against
the MEPs learned through continuity check messages 1008
Show Shows list of configured remote maintenance end points 1008
Configure Periodic Delay Measure Configures periodic transmission of delay-measure messages 1010
Add Group Configures a delay-measure attribute group 1010
Show Group Shows delay-measure attribute groups 1010
Configure Transmits perioic delay-measure messages 1010
Configure Periodic Loss Measure Configures periodic transmission of loss-measure messages 1014
Add Single-Ended LM Group Configures a single-ended loss-measure attribute group 1014
Show Single-Ended LM Group Shows single-ended loss-measure attribute groups 1014
Configure Single-Ended LM Transmits periodic single-ended loss-measure messages 1014
TABLE 153 Switch Main Menu (Continued)
Menu Description Page
