Brocade 6910 Ethernet Access Switch Configuration Guide 401
53-1002651-02
20
Configuring Protocol-based VLANs
protocol-vlan protocol-group (Configuring Groups)
This command creates a protocol group, or to add specific protocols to a group. Use the no form to
remove a protocol group.
Syntax
protocol-vlan protocol-group group-id [{add | remove} frame-type frame protocol-type protocol]
no protocol-vlan protocol-group group-id
group-id - Group identifier of this protocol group. (Range: 1-2147483647)
frame
11
- Frame type used by this protocol. (Options: ethernet, rfc_1042, llc_other)
protocol - Protocol type. The only option for the llc_other frame type is ipx_raw. The options
for all other frames types include: arp, ip, ipv6, rarp.
Default Setting
No protocol groups are configured.
Command Mode
Global Configuration
Example
The following creates protocol group 1, and specifies Ethernet frames with IP and ARP protocol
types:
Console(config)#protocol-vlan protocol-group 1 add frame-type ethernet
protocol-type ip
Console(config)#protocol-vlan protocol-group 1 add frame-type ethernet
protocol-type arp
Console(config)#
protocol-vlan protocol-group (Configuring Interfaces)
This command maps a protocol group to a VLAN for the current interface. Use the no form to
remove the protocol mapping for this interface.
Syntax
protocol-vlan protocol-group group-id vlan vlan-id priority priority
no protocol-vlan protocol-group group-id vlan
group-id - Group identifier of this protocol group. (Range: 1-2147483647)
vlan-id - VLAN to which matching protocol traffic is forwarded. (Range: 1-4093)
priority – The priority assigned to untagged ingress traffic. (Range: 0-7, where 7 is the
highest priority)
Default Setting
No protocol groups are mapped for any interface.
11. SNAP frame types are not supported by this switch due to hardware limitations.
