Brocade 6910 Ethernet Access Switch Configuration Guide (Supporting R2.2.0.0) - Manual (Page 181)

Brocade 6910 Ethernet Access Switch Configuration Guide 125
53-1002651-02
Chapter
7
Remote Monitoring Commands
In this chapter
Remote Monitoring allows a remote device to collect information or respond to specified events on
an independent basis. This switch is an RMON-capable device which can independently perform a
wide range of tasks, significantly reducing network management traffic. It can continuously run
diagnostics and log information on network performance. If an event is triggered, it can
automatically notify the network administrator of a failure and provide historical information about
the event. If it cannot connect to the management agent, it will continue to perform any specified
tasks and pass data back to the management station the next time it is contacted.
This switch supports mini-RMON, which consists of the Statistics, History, Event and Alarm groups.
When RMON is enabled, the system gradually builds up information about its physical interfaces,
storing this information in the relevant RMON database group. A management agent then
periodically communicates with the switch using the SNMP protocol. However, if the switch
encounters a critical event, it can automatically send a trap message to the management agent
which can then respond to the event if so configured.
TABLE 31 RMON Commands
Command Function Mode
rmon alarm Sets threshold bounds for a monitored variable GC
rmon event Creates a response event for an alarm GC
rmon collection history Periodically samples statistics IC
rmon collection rmon1 Enables statistics collection IC
show rmon alarms Shows the settings for all configured alarms PE
show rmon events Shows the settings for all configured events PE
show rmon history Shows the sampling parameters for each entry PE
show rmon statistics Shows the collected statistics PE
