Brocade 6910 Ethernet Access Switch Configuration Guide (Supporting R2.2.0.0) - Manual (Page 1130)

1074 Brocade 6910 Ethernet Access Switch Configuration Guide
53-1002651-02
44
Address Resolution Protocol
FIGURE 352 Displaying Local ARP Entries
Displaying ARP Statistics
Use the IP > ARP (Show Information) page to display statistics for ARP messages crossing all
interfaces on this router.
CLI References
• “show ip traffic” on page 598
Parameters
These parameters are displayed:
Interface
To display ARP statistics:
1. Click IP, ARP.
2. Select Show Information from the Step List.
3. Click Statistics.
FIGURE 353 Displaying ARP Statistics
TABLE 186 ARP Statistics
Parameter Description
Received Request Number of ARP Request packets received by the router.
Received Reply Number of ARP Reply packets received by the router.
Sent Request Number of ARP Request packets sent by the router.
Sent Reply Number of ARP Reply packets sent by the router.
