Brocade 6910 Ethernet Access Switch Configuration Guide 549
53-1002651-02
25
CFM Commands
Example
Console#show ethernet cfm linktrace-cache
Hops MA IP / Alias Ingress MAC Ing. Action Relay
Forwarded Egress MAC Egr. Action
---- -------------- ----------------------- ----------------- ----------- -----
2 rd 192.168.0.6 00-12-CF-12-12-2D ingOk Hit
Not Forwarded
Console#
TABLE 129 show ethernet cfm linktrace-cache - display description
Field Description
Hops The number hops taken to reach the target MEP.
MA Name of the MA to which this device belongs.
IP/Alias IP address or alias of the target device.
Forwarded Shows whether or not this link trace message was forwarded. A message is not
forwarded if received by the target MEP.
Ingress MAC MAC address of the ingress port on the target device.
Egress MAC MAC address of the egress port on the target device.
Ing. Action Action taken on the ingress port:
IngOk – The target data frame passed through to the MAC Relay Entity.
IngDown – The bridge port’s MAC_Operational parameter is false. This value could be
returned, for example, by an operationally Down MEP that has another Down MEP at a
higher MD level on the same bridge port that is causing the bridge port’s
MAC_Operational parameter to be false.
IngBlocked – The ingress port can be identified, but the target data frame was not
forwarded when received on this port due to active topology management, i.e., the
bridge port is not in the forwarding state.
IngVid – The ingress port is not in the member set of the LTM’s VIDs, and ingress
filtering is enabled, so the target data frame was filtered by ingress filtering.
Egr. Action Action taken on the egress port:
EgrOk – The targeted data frame was forwarded.
EgrDown – The Egress Port can be identified, but that bridge port’s MAC_Operational
parameter is false.
EgrBlocked – The egress port can be identified, but the data frame was not passed
through the egress port due to active topology management, i.e., the bridge port is not
in the forwarding state.
EgrVid – The Egress Port can be identified, but the bridge port is not in the LTM’s VID
member set, and was therefore filtered by egress filtering.
Relay Relay action:
FDB – Target address found in forwarding database.
MPDB – Target address found in the maintenance point database.
HIT – Target located on this device.
