Brocade 6910 Ethernet Access Switch Configuration Guide (Supporting R2.2.0.0) - Manual (Page 759)

Brocade 6910 Ethernet Access Switch Configuration Guide 703
53-1002651-02
34
Port Configuration
• Speed/Duplex – Allows you to manually set the port speed and duplex mode. (i.e., with
auto-negotiation disabled)
• Flow Control – Allows automatic or manual selection of flow control.
Interface
To configure port connection parameters:
1. Click Interface, Port, General.
2. Select Configure by Port List from the Action List.
3. Modify the required interface settings.
4. Click Apply.
FIGURE 32 Configuring Connections by Port List
Configuring by Port Range
Use the Interface > Port > General (Configure by Port Range) page to enable/disable an interface,
set auto-negotiation and the interface capabilities to advertise, or manually fix the speed, duplex
mode, and flow control.
For more information on command usage and a description of the parameters, refer to
“Configuring by Port List” on page 701.
CLI References
• “Interface Commands” on page 255
Interface
To configure port connection parameters:
1. Click Interface, Port, General.
2. Select Configure by Port Range from the Action List.
3. Enter to range of ports to which your configuration changes apply.
