670 Brocade 6910 Ethernet Access Switch Configuration Guide
53-1002651-02
32
Navigating the Web Browser Interface
Configure Dual-Ended LM Transmits periodic dual-ended loss-measure messages 1014
Transmit Link Trace Sends link trace messages to isolate connectivity faults by
tracing the path through a network to the designated target node 1018
Transmit Loopback Sends loopback messages to isolate connectivity faults by requesting a
target node to echo the message back to the source 1020
Transmit Delay Measure Sends on-demand delay-measure requests 1021
Execute Two-Way DM Sends DM frames to a peer MEP, and awaits return DMM frames from it 1021
Execute One-Way DM Sends DM frames to a peer MEP 1021
Transmit Single-Ended Loss Measure Send on-demand single-ended loss-measure requests, and awaits return
LMR frames from it 1024
Show Information
Show Local MEP Shows the MEPs configured on this device 1026
Show Local MEP Details Displays detailed CFM information about a specified local MEP in the
continuity check database 1027
Show Local MIP Shows the MIPs on this device discovered by the CFM protocol 1029
Show Remote MEP Shows MEPs located on other devices which have been discovered
through continuity check messages, or statically configured in the MEP
database 1030
Show Remote MEP Details Displays detailed CFM information about a specified remote MEP in the
continuity check database 1031
Show Link Trace Cache Shows information about link trace operations launched from this device 1033
Show Fault Notification Generator Displays configuration settings for the fault notification generator 1035
Show Continuity Check Error Displays CFM continuity check errors logged on this device 1036
Show Two-Way Delay-Measure Results Displays on-demand delay-measure requests logged on this device
Show Single-Ended Loss-Measure
Results
Displays on-demand loss-measure requests logged on this device
OAM Operation, Administration, and Maintenance 1038
Interface Enables OAM on specified port, sets the mode to active or passive, and
enables the reporting of critical events or errored frame events 1038
Counters Displays statistics on OAM PDUs 1041
Event Log Displays the log for recorded link events 1042
Remote Interface Displays information about attached OAM-enabled devices 1043
Remote Loopback Performs a loopback test on the specified port 1044
IP 1047
General
Routing Interface
Add Address Configures an IP interface for a VLAN 1047
Show Address Shows the IP interfaces assigned to a VLAN 1047
Ping Sends ICMP echo request packets to another node on the network 1066
TABLE 153 Switch Main Menu (Continued)
Menu Description Page
