7-24 Xstudio User Manual
Animating scene objects
Opening the Animation Editor
Building an animated scene occurs within the Animation Editor, which is an Xstudio tool
located within a collapsible panel at the bottom of the Xstudio interface in Design mode.
Since the Animation Editor is used only to animate objects on scenes, it is only available
when the Scene tab is selected. When the control-side is selected, the Action Editor
appears in this collapsible panel.
To open the Animation Editor:
•
With the scene-side open (the scene tab selected), click the center of the gripper bar
the bottom of the screen.
Or,
•
Press C TRL + E on your keyboard.
Figure 7-11. Click the gripper bar at the bottom of the Xstudio screen to open/close the Animation Editor
N
OTE
You can resize the Animation Editor by dragging the gripper’s blue boundary along the top
of the Animation Editor until it is the desired height.
Gripper bar
