842 Brocade Mobility Access Point System Reference Guide
53-1003100-01
13
The TSPEC screen provides information about TSPEC counts and TSPEC types utilized by the
selected wireless client.
To view the TSPEC statistics:
1. Select the Statistics menu from the Web UI.
2. Select System from the navigation pane (on the left-hand side of the screen). Expand a RF
Domain, an access point, then a connected client.
3. Select WMM TPSEC.
FIGURE 98 Wireless Client - WMM TPSEC screen
The top portion of the screen displays the TSPEC stream type and whether the client has roamed.
The Ports Stats field displays the following:
4. Periodically select Refresh to update the screen to its latest values.
Sequence Number Lists a sequence number that’s unique to this WMM TPSEC uplink or downlink data stream.
Direction Type Displays whether the WMM TPSEC data stream is in the uplink or downlink direction.
Request Time Lists each sequence number’s request time for WMM TPSEC traffic in the specified direction.
This is time allotted for a request before packets are actually sent.
Used Time Displays the time the client used TSPEC. The client sends a delete traffic stream (DELTS)
message when it has finished communicating.
TID Displays the parameter for defining the traffic stream. TID identifies data packets as belonging
to a unique traffic stream.
