Brocade Mobility Access Point System Reference Guide (Supporting software release 5.5.0.0 and later) - Manual (Page 525)

Brocade Mobility Access Point System Reference Guide 515
53-1003100-01
7
FIGURE 18 AAA TACACS Policy - New Accounting Server
NOTE
Only 2 AAA TACACS accounting servers can be configured at a time.
13. Define the following settings to add or modify AAA TACACS accounting server configuration:
14. Click OK to close the Accounting Server dialog and save the changes. Click Reset to revert to
the last saved configuration. Click Exit to close the Accounting Server dialog.
15. Click the Authorization tab.
Server Id Displays the numerical server index (1-2) for the accounting server when added to the list available
to the access point.
Host Specify the IP address or hostname of the AAA TACACS accounting server.
Port Define or edit the port on which the AAA TACACS server listens to traffic within the access point
managed network. The port range is 1 - 65,535. The default port is 49.
Secret Specify the secret (password) used for authentication on the selected AAA TACACS server. By
default the secret is displayed as asterisks.
When a secret is entered, it must be confirmed in the Reconfirm text box.
Request Attempts Displays the number of attempts a client can retransmit a missed frame to the AAA TACACS server
before it times out of the authentication session. The available range is from 1 - 10. The default is 3.
Request Timeout Specify the time for the access point’s re-transmission of request packets. The default is 3 seconds.
If this time is exceeded, the authentication session is terminated.
Retry Timeout Factor Specifies the interval, in seconds, between two successive re-transmission attempts of request
packets. Specify a value from 50 - 200 seconds. The default is 100 seconds.
