806 Brocade Mobility Access Point System Reference Guide
53-1003100-01
13
6. The DHCP Manual Bindings table displays the following:
DHCP Bindings
DHCP Server
The DHCP Binding screen displays DHCP binding expiry time, client IP addresses and their MAC
address.
To view a network’s DHCP Bindings:
1. Select the Statistics menu from the Web UI.
2. Select System from the navigation pane (on the left-hand side of the screen). Expand a RF
Domain and select one of its connected access points.
3. Select DHCP and expand the menu to reveal its sub menu items.
4. Select Bindings.
FIGURE 72 Access Point - DHCP Server Bindings screen
IP Address Displays the IP address for clients requesting DHCP provisioning resources.
Client Id Displays the client’s ID used to differentiate requesting clients.
Refresh Select the Refresh button to update the screen’s statistics counters to their
latest values.
