598 Brocade Mobility Access Point System Reference Guide
53-1003100-01
9
FIGURE 17 RADIUS Group Policy Add screen
4. Define the following Settings to define the user group configuration:
RADIUS Group Policy If creating a new RADIUS group, assign it a name to help differentiate it from others with
similar configurations. The name cannot exceed 32 characters or be modified as part of a
RADIUS group edit process.
Guest User Group Select this option to assign only guest access and temporary permissions to the local
RADIUS server. Guest user groups cannot be made management groups with unique
access and role permissions. This setting is disabled by default.
VLAN Select this option (and use the slider) to assign a specific VLAN to this RADIUS user group.
Ensure Dynamic VLAN assignment (Single VLAN) is enabled for the WLAN for the VLAN to
work properly. For more information, see Basic WLAN Configuration on page 6-395.
WLAN SSID Assign a list of SSIDs (users) the RADIUS group are allowed to associate to. An SSID
cannot exceed 32 characters. Assign WLAN SSIDs representative of users a guest user
will need to access. The parameter is not available if this RADIUS group has been defined
as a management group.
Rate Limit from Air Select the check box to set an uplink rate limit for managed clients within this RADIUS
group. Use the spinner to set value from 100 - 1,000,000 kbps. Setting a value of 0
disables rate limiting.
