186 Brocade Mobility Access Point System Reference Guide
53-1003100-01
5
FIGURE 84 Profile Security - Dynamic NAT screen
7. Select the ACL whose IP rules are to be applied to this policy based forwarding rule. A new ACL
can be defined by selecting the Create icon, or an existing set of IP ACL rules can be modified
by selecting the Edit icon.
8. Use the IP Address Range table to configure IP addresses and address ranges that can used to
access the Internet.
9. Select + Add Row to set the IP address range settings for the Bridge NAT configuration.
Interface Lists the outgoing layer 3 interface on which traffic is re-directed. The interface can be an access
point WWAN or PPPoE interface. Traffic can also be redirected to a designated VLAN.
NAT Pool Displays the NAT pool used by this Bridge NAT entry. A value is only displayed only when Overload
Type has been set to NAT Pool.
Overload IP Lists whether a single global address collectively supports numerous local addresses.
Overload Type Displays the override type for this policy based forwarding rule.
