Brocade Mobility Access Point System Reference Guide 105
53-1003100-01
5
802.11ac MCS rates are defined as follows both with and without short guard intervals (SGI):
WAN Backhaul Configuration
Profile Interface Configuration
A Wireless Wide Area Network (WWAN) card is a specialized network interface card that allows a
network device to connect, transmit and receive data over a Cellular Wide Area Network. The
Brocade Mobility 7131 Access PointN model access point has a PCI Express card slot that supports
3G WWAN cards. The WWAN card uses point to point protocol (PPP) to connect to the Internet
Service Provider (ISP) and gain access to the Internet. PPP is the protocol used for establishing
internet links over dial-up modems, DSL connections, and many other types of point-to-point
communications. PPP packages your system’s TCP/IP packets and forwards them to the serial
device where they can be put on the network. PPP is a full-duplex protocol that can be used on
various physical media, including twisted pair or fiber optic lines or satellite transmission. It uses a
variation of High Speed Data Link Control (HDLC) for packet encapsulation.
The following 3G cards are supported:
• Verizon V740
• Verizon PC770
• Sprint C777
• Novatel Merlin XU870
• Sierra Aircard 880E
• Telstra Elite Mobile Broadband
• Option GT Ultra Express
• Vodaphone Mobile Connect E3730
• Aircard 503
• Aircard 504 / AT & T 890
To define a WAN Backhaul configuration:
1. Select the Configuration tab from the Web UI.
2. Select Devices.
MCS Index 20 MHz
No SGI 20 MHz With
SGI 40 MHz
No SGI 40MHz
With SGI 80 MHz
No SGI 80MHz
With SGI
0 6.5 7.2. 13.5 15 29.3 32.5
1 13 14.4 27 30 58.5 65
2 19.5 21.7 40.5 45 87.8 97.5
3 26 28.9 54 60 117 130
4 39 43.3 81 90 175.5 195
5 52 57.8 108 120 234 260
6 58.5 65 121.5 135 263.3 292.5
7 65 72.2 135 150 292.5 325
8 78 86.7 162 180 351 390
9 n/a n/a 180 200 390 433.3
