The DHCP Bindings screen displays the following:
DHCP Networks
DHCP Server
The DHCP server maintains a pool of IP addresses and client configuration parameters (default
gateway, domain name, name servers etc). On receiving a valid client request, the server assigns
the computer an IP address, a lease (the validity of time), and other IP configuration parameters.
The Networks screen provides network pool information such as the subnet for the addresses you
want to use from the pool, the pool name, the used addresses and the total number of addresses.
To view a network’s DHCP Networks:
1. Select the Statistics menu from the Web UI.
2. Select System from the navigation pane (on the left-hand side of the screen). Expand the a RF
Domain and select one of its connected access points.
3. Select DHCP and expand the menu to reveal its sub menu items.
4. Select Networks.
The DHCP Networks screen displays the following:
Expiry Time Displays the expiration of the lease used by a requesting client for DHCP resources.
IP Address Displays the IP address for each DHCP resource requesting client.
DHCP MAC Address Displays the hardware encoded MAC address (client Id) of each DHCP resource requesting
client.
Clear Select a table entry and select Clear to remove the client from the list of devices requesting
DHCP services.
Clear All Select Clear All to remove all listed clients from this list of DHCP resource requesting clients.
Refresh Select Refresh to update the statistics counters to their latest values.
