When creating or modifying a WLAN, the Basic Configuration screen is the first screen that displays
as part of the WLAN configuration screen flow. Use this screen to enable a WLAN, and define its
SSID, client behavior and VLAN assignments.

1. Select the Configuration tab from the Web UI.

2. Select Wireless.

3. Select Wireless LANs to display a high level display of existing WLANs.

4. Select the Add button to create an additional WLAN, or select Edit to modify selected WLAN’s

properties. WLANs can also be removed as they become obsolete by selecting Delete.

DHCP Option 82

Displays if DHCP Option 82 is enabled or not. DHCP option 82 provides additional
information on the physical attachment of a client

Authentication Type

Displays the name of the authentication scheme used by each listed WLAN to secure
client transmissions. None is listed if authentication is not used within a WLAN. In case of
no authentication, refer to the Encryption Type column to verify if there is some sort of
data protection used with the WLAN, or risk using this WLAN with no protection at all.

Encryption Type

Displays the name of the encryption scheme used by each listed WLAN to secure client
membership transmissions. None is listed if encryption is not used within this WLAN. In
case of no encryption, refer to the Authentication Type column to verify if there is some
sort of data protection used with the WLAN or risk using this WLAN with no protection at
all.

QoS Policy

Lists the QoS policy applied to each listed WLAN. A QoS policy needs to be custom
selected (or created) for each WLAN in respect to the WLAN’s intended client traffic, and
the voice, video or normal data traffic it supports.

Association ACL

Lists the Association ACL policy applied to each listed WLAN. An Association ACL is a
policy-based Access Control List (ACL) that either prevents or allows wireless clients from
connecting to a access point managed WLAN. The mapping of an Association ACL is
strictly optional.
