Brocade Mobility Access Point System Reference Guide 707
53-1003100-01
13
Refer to the following license utilization data:
RF Domain Statistics
Statistics
The RF Domain screens display status for a selected RF domain. This includes the RF Domain
health and device inventory, wireless clients and Smart RF functionality. RF Domains allow
administrators to assign regional, regulatory and RF configuration to devices deployed in a
common coverage area such as on a building floor, or site. Each RF Domain contains regional,
regulatory and sensor server configuration parameters and may also be assigned policies that
determine Access, SMART RF and WIPS configuration.
Use the following information to obtain an overall view of the performance of the selected RF
Domain and troubleshoot issues with the domain or any member device.
• Health
• Inventory
• Devices
• AP Detection
• Wireless Clients
Cluster/Hostname Lists the administrator assigned cluster hostname whose license count and
utilization is listed and tallied for access points.
AP Licenses Installed Lists the number of access point connections available to this peer access
point under the terms of the current license.
Borrowed AP Licenses Displays the number of access point licenses temporarily borrowed from a
cluster member to compensate for an AP license deficiency.
Total AP Licenses Displays the total number of access point connection licenses currently
available to clustered devices.
AP Licenses Usage Lists the number of access point connections currently utilized out of the total
available under the terms of current licenses.
Remaining AP Licenses Lists the remaining number of AP licenses available from the pooled license
capabilities of cluster members.
AAP Licenses Installed Lists the number of Adaptive Access Point connections available under the
terms of current licenses.
Borrowed AAP Licenses Displays the number of Adaptive Access Point licenses temporarily borrowed
from a cluster member to compensate for an AAP license deficiency.
Total AAP Licenses Displays the total number of Adaptive Access Point connection licenses
currently available to clustered devices.
AAP Licenses Usage Lists the number of Adaptive Access Point connections currently utilized out of
the total available under the terms of the current licenses.
Remaining AAP Licenses Lists the remaining number of AAP licenses available from the pooled license
capabilities of all the members of the cluster.
Validity Displays validity information for the license’s legal usage by cluster member
devices.
Refresh Select Refresh to update the screen’s statistics counters to their latest values.
