Brocade Mobility Access Point System Reference Guide 243
53-1003100-01
5
FIGURE 122 Device Overrides -RF Domain Overrides screen
NOTE
A blue override icon (to the left of a parameter) defines the parameter as having an override applied.
To remove a device’s override, go to the Basic Configuration screen’s Device Overrides field, and
then select the Clear Overrides button.
Refer to the Basic Configuration field to review the basic settings defined for the target device’s RF
Domain configuration, and optionally assign/remove overrides to and from specific parameters.
Refer to the Statistics field to set the following:
Click + Add Row button to add upto two (2) rows to the Statistics field.
Select OK to save the changes and overrides made to the RF Domain configuration. Selecting
Reset reverts the screen to its last saved configuration.
Location Set the deployment location for the access point as part of its RF Domain configuration.
Contact Set the administrative contact for the access point. This should reflect the administrator
responsible for the access point’s configuration and wireless network.
Time Zone Use the drop-down menu to select the geographic time zone supporting its deployment location.
Country Code Use the drop-down menu to select the country code supporting its deployment location.
Window Index Use the spinner control to set a numerical index used as an identifier for each RF Domain statistics
configuration defined.
Sample Interval Use the spinner control to define the interval (in seconds) used to capture statistics supporting the
listed RF Domain configuration. The default is 5 seconds.
Window Size Use the spinner control to set the number of samples used to define RF Domain statistics. The
default value is 3 samples.
