Brocade Mobility Access Point System Reference Guide (Supporting software release 5.5.0.0 and later) - Manual (Page 397)

Brocade Mobility Access Point System Reference Guide 387
53-1003100-01
5
Select the VLAN tab to display the link IP VLAN information shared by the access points managed
by the MINT configuration.
FIGURE 215 Device Overrides - Advanced Profile MINT screen - VLAN tab
The VLAN tab displays the VLAN, Routing Level, Link Cost, Hello Packet Interval and Adjacency Hold
Time managed devices use to securely communicate amongst one another.
Select Add to create a new VLAN link configuration or Edit to override an existing MINT
configuration.
NOTE
If creating a mesh link between two access points in Standalone AP mode, you’ll need to ensure a
VLAN is available to provide the necessary MINT link between the two Standalone APs.
Hello Packet Interval Set or override an interval in either Seconds (1 - 120) or Minutes (1 - 2) for the transmission of
hello packets. The default interval is 15 seconds.
Adjacency Hold Time Set or override a hold time interval in either Seconds (2 - 600) or Minutes
(1 - 10) for the transmission of hello packets. The default interval is 46 seconds.
IPSec Secure Select this option to use a secure link for IPSec traffic. This setting is disabled by default. When
enabled, both the header and the traffic payload are encrypted.
IPSec GW Define either an IP address or hostname for the IPSec gateway.
