654 Brocade Mobility Access Point System Reference Guide
53-1003100-01
12
Use the Summary screen to assess whether a device’s firmware or configuration file requires an
update to the latest feature set and functionality. To view the Summary screen:
Select Operations.
Select Devices.
Use the navigation pane on the left to navigate to the device to manage the firmware and
configuration files on and select it.
The Device Details Summary screen displays by default. when the Operations menu item is
selected from the main menu.
NOTE
When displaying the Summary screen at the RF Domain level of the UI’s hierarchal tree, the screen
does not display a field for a device’s Primary and Secondary firmware image. At the RF Domain
level, the Summary screen just lists the Hostname, MAC Address, Online status, Device Type and Is
Controller designations for the devices comprising the selected RF Domain. A RF Domain must be
selected from the hierarchal tree and expanded to list the devices comprising the RF Domain. From
there, individual controllers, service platforms and Access Points can be selected and their
properties modified.
FIGURE 21 Device Details screen
