Brocade Mobility Access Point System Reference Guide (Supporting software release 5.5.0.0 and later) - Manual (Page 395)

Brocade Mobility Access Point System Reference Guide 385
53-1003100-01
5
Define or override the following MINT Link Settings:
Select the Tunnel Controller Load Balancing (Level1) option to enable load balancing on the tunnel
controller.
Define the group name of clustered tunnel controllers in the Preferred Tunnel Controller Name
field.
Select OK to save the changes and overrides made to the Settings tab. Select Reset to revert to the
last saved configuration.
Select the IP tab to display the link IP network address information shared by the devices managed
by the MINT configuration.
FIGURE 213 Device Overrides - Advanced Profile MINT screen - IP tab
The IP tab displays the IP address, Routing Level, Listening Link, Port, Forced Link, Link Cost, Hello
Packet Interval and Adjacency Hold Time managed devices use to securely communicate amongst
one another.
Select Add to create a new Link IP configuration or Edit to override an existing MINT configuration.
MLCP IP Select this option to enable MINT Link Creation Protocol (MLCP) by IP Address. MINT Link
Creation Protocol is used to create one UDP/IP link from the device to a neighbor. That
neighboring device can be another AP.
MLCP VLAN Select this option to enable MLCP by VLAN. MLCP is used to create one VLAN link from the
device to a neighbor. That neighboring device can be another AP.
Tunnel MiNT across extended
VLAN Select this option to enable tunneling MiNT protocol packets across extended VLANs.
