236 Brocade Mobility Access Point System Reference Guide
53-1003100-01
5
Define the following configuration parameters required to import a RSA key:
Select OK to import the defined RSA key. Select Cancel to revert the screen to its last saved
configuration.
To optionally export a RSA key to a remote location, select the Export button from the RSA Keys
screen.
Export the key to a RADIUS server so it can be imported without generating a second key. If there
are more than one RADIUS authentication server, export the certificate and do not generate a
second key unless you want to deploy two root certificates.
Key Name Enter the 32 character maximum name assigned to the RSA key
Key Passphrase Define the key used by both the access point and the server (or repository) of the target RSA key.
Select the Show option to expose the actual characters used in the passphrase. Leaving the Show
option unselected displays the passphrase as a series of asterisks “*”.
URL Provide the complete URL to the location of the RSA key.
Protocol If selecting Advanced, select the protocol used for importing the target key. Available options
include:
•
tftp
•
ftp
•
sftp
•
http
•
cf
•
usb1
•
usb2
Port If selecting Advanced, use the spinner control to set the port. This option is not valid for cf, usb1
and usb2.
IP Address If selecting Advanced, enter IP address of the server used to import the RSA key. This option is not
valid for cf, usb1 and usb2.
Host If selecting Advanced, provide the hostname of the server used to import the RSA key. This option is
not valid for cf, usb1 and usb2.
Username/Password These fields are enabled if using ftp or sftp protocols,. Specify the username and the password for
that username to access the remote servers using these protocols.
Path/File If selecting Advanced, specify the path to the RSA key. Enter the complete relative path to the key
on the server.
