Brocade Mobility Access Point System Reference Guide (Supporting software release 5.5.0.0 and later) - Manual (Page 481)

Brocade Mobility Access Point System Reference Guide 471
53-1003100-01
6
FIGURE 35 SMART RF Recovery Configuration screen - Neighbor Recovery tab
18. Set the following Neighbor Recovery variables for the Smart RF configuration:
NOTE
The recovery parameters within the Neighbor Recovery, Interference and Coverage Hole Recovery
tabs are only enabled when Custom is selected as the Sensitivity setting from the Smart RF Basic
Configuration screen.
Power Hold Time Defines the minimum time between two radio power changes during neighbor recovery. Set the
time in either Seconds (0 - 3,600), Minutes (0 - 60) or Hours (0 - 1). The default setting is 0
seconds.
5GHz Neighbor Power
Threshold Use the spinner control to set a value from -85 to -55 dBm the access point’s 5.0 GHz radio uses as
a maximum power increase threshold if the radio is required to increase its output power to
compensate for a failed radio within the access point’s radio coverage area. The default value is -70
dBm.
2.4 GHz Neighbor Power
Threshold Use the spinner control to set a value from -85 to -55 dBm the access point’s 2.4 GHz radio uses as
a maximum power increase threshold if the radio is required to increase its output power to
compensate for a failed radio within the access point’s radio coverage area. The default value is -70
dBm.
