Brocade Mobility Access Point System Reference Guide 749
53-1003100-01
13
3. Select Captive Portal from the RF Domain menu.
FIGURE 30 RF Domain - Captive Portal
The screen displays the following Captive Portal data for requesting clients:
Access Point Statistics
Statistics
The Access Point statistics screens displays controller or service platform connected access point
performance, health, version, client support, radio, mesh, interface, DHCP, firewall, WIPS, sensor,
captive portal, NTP and load information. Access point statistics consists of the following:
• Health
Client MAC Displays the MAC address of each listed client requesting captive portal access to the
controller or service platform managed network. This address can be selected to display
client information in greater detail.
Hostname Lists the administrator assigned hostname of the device requesting captive portal access
to network’s Rf Domain resources.
Client IP Displays the IP address of each listed client using its connected RF Domain member
access point for captive portal access.
Captive Portal Lists the name of the RF Domain captive portal currently being utilized by each listed
client.
Authentication Displays the authentication status of requesting clients attempting to connect to the
access point via the captive portal.
WLAN Displays the name of the WLAN the requesting client would use for interoperation with the
access point.
VLAN Displays the name of the VLAN the client would use as a virtual interface for captive
portal operation with the access point.
Remaining Time Displays the time after which a connected client is disconnected from the captive portal.
Refresh Select the Refresh button to update the statistics counters to their latest values.
