2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual 2-67
Special D Function
ES
EX
SS
SA
SX
SC
EH
EH2
SV
Off
Ø
On
STOP
Ø
RUN
RUN
Ø
STOP
Attribute Latched Default
D1608*
↓
D1623*
Data buffer to store the data read from Slave ID#5 ╳ ○ ○ - - - R YES 0
D1624*
↓
D1639*
Data buffer to store the data to be written on Slave
ID#5
╳ ○ ○ - - - R/W YES 0
D1640*
↓
D1655*
Data buffer to store the data read from Slave ID#6 ╳ ○ ○ - - - R YES 0
D1656*
↓
D1671*
Data buffer to store the data to be written on Slave
ID#6
╳ ○ ○ - - - R/W YES 0
D1672*
↓
D1687*
Data buffer to store the data read from Slave ID#7 ╳ ○ ○ - - - R YES 0
D1688*
↓
D1703*
Data buffer to store the data to be written on Slave
ID#7
╳ ○ ○ - - - R/W YES 0
D1704*
↓
D1719*
Data buffer to store the data read from Slave ID#8 ╳ ○ ○ - - - R YES 0
D1720*
↓
D1735*
Data buffer to store the data to be written on Slave
ID#8
╳ ○ ○ - - - R/W YES 0
D1736*
↓
D1751*
Data buffer to store the data read from Slave ID#9 ╳ ○ ○ - - - R YES 0
D1752*
↓
D1767*
Data buffer to store the data to be written on Slave
ID#9
╳ ○ ○ - - - R/W YES 0
D1768*
↓
D1783*
Data buffer to store the data read from Slave ID#10 ╳ ○ ○ - - - R YES 0
D1784*
↓
D1799*
Data buffer to store the data to be written on Slave
ID#10
╳ ○ ○ - - - R/W YES 0
D1800*
↓
D1815*
Data buffer to store the data read from Slave ID#11 ╳ ○ ○ - - - R YES 0
