2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual 2-37
Special
M
Function
ES
EX
SS
SA
SX
SC
EH
EH2
SV
Off
Ø
On
STOP
Ø
RUN
RUN
Ø
STO
P
Attribute Latched Default
M1085 Selecting DVP-PCC01 duplicating function ○ ○ ○ Off - - R/W NO Off
M1086
Setting up the switch for enabling password function
of DVP-PCC01
○ ○ ○ Off - - R/W NO Off
M1087* Enabling LV signal ╳ ╳ ○ Off - - R/W NO Off
M1088
Matrix comparison.
Comparing between equivalent values (M1088 = 1)
or different values (M1088 = 0). ╳ ○ ○ Off Off - R/W NO Off
M1089
Matrix search end flag. When the comparison
reaches the last bit, M1089 = 1.
╳ ○ ○ Off Off - R NO Off
M1090
Matrix search start flag. Comparing from bit 0
(M1090 = 1).
╳ ○ ○ Off Off - R NO Off
M1091
Matrix bit search flag. When the comparison is
completed, the comparison will stop immediately
(M1091=1).
╳ ○ ○ Off Off - R NO Off
M1092
Matrix pointer error flag. When the pointer Pr
exceeds its range, M1092 = 1.
╳ ○ ○ Off Off - R NO Off
M1093
Matrix pointer increasing flag. Adding 1 to the
current value of the Pr.
╳ ○ ○ Off Off - R/W NO Off
M1094
Matrix pointer clear flag. Clearing the current value
of the Pr to 0.
╳ ○ ○ Off Off - R/W NO Off
M1095 Matrix rotation/displacement/output carry flag ╳ ○ ○ Off Off - R NO Off
M1096 Matrix displacement/input complement flag ╳ ○ ○ Off Off - R/W NO Off
M1097 Matrix rotation/displacement direction flag ╳ ○ ○ Off Off - R/W NO Off
M1098
Matrix counting the number of bits which are “1” or
“0”
╳ ○ ○ Off Off - R/W NO Off
M1099 On when the matrix counting result is “0” ╳ ○ ○ Off Off - R/W NO Off
M1100 SPD instruction sampling once ╳ ╳ ○ Off - - R/W NO Off
M1101* Whether to enable file registers ╳ ○ ○ - - - R/W Yes Off
M1102 Y10 pulse output ends (For SC) ╳ ○ ╳ Off - - R/W NO Off
M1103 Y11 pulse output ends (For SC) ╳ ○ ╳ Off - - R/W NO Off
M1104*
Status of SW1 on digital switch card/AX0 input point
on 4DI card (photpcoupler isolation)
╳ ╳ ○ Off Off - R NO Off
M1105*
Status of SW2 on digital switch card/AX1 input point
on 4DI card (photpcoupler isolation)
╳ ╳ ○ Off Off - R NO Off
M1106*
Status of SW3 on digital switch card/AX2 input point
on 4DI card (photpcoupler isolation)
╳ ╳ ○ Off Off - R NO Off
M1107*
Status of SW4 on digital switch card/AX3 input point
on 4DI card (photpcoupler isolation)
╳ ╳ ○ Off Off - R NO Off
M1108* Status of SW5 on digital switch card ╳ ╳ ○ Off Off - R NO Off
