9 Application Instructions API 150-199
DVP-PLC Application Manual 9-3
Registers for sent data (sending messages)
Register DATA Explanation
D1256 Low ‘0’ 30 H ADR 1
D1256 High ‘1’ 31 H ADR 0
Address of AC motor drive: ADR (1,0)
D1257 Low ‘0’ 30 H CMD 1
D1257 High ‘3’ 33 H CMD 0
Instruction code: CMD (1,0)
D1258 Low ‘2’ 32 H
D1258 High ‘1’ 31 H
D1259 Low ‘0’ 30 H
D1259 High ‘0’ 30 H
Starting Data Address
D1260 Low ‘0’ 30 H
D1260 High ‘0’ 30 H
D1261 Low ‘0’ 30 H
D1261 High ‘6’ 36 H
Number of Data (counted by words)
D1262 Low ‘D’ 44 H LRC CHK 1
D1262 High ‘5’ 35 H LRC CHK 0
Error checksum: LRC CHK (0,1)
Registers for received data D0 (responding messages)
Register DATA Explanation
D0 Low ‘0’ 30 H ADR 1
D0 High ‘1’ 31 H ADR 0
D1 Low ‘0’ 30 H CMD 1
D1 High ‘3’ 33 H CMD 0
D2 Low ‘0’ 30 H
D2 High ‘C’ 43 H
Number of Data (counted by byte)
D3 Low ‘0’ 30 H
D3 High ‘1’ 31 H
D4 Low ‘0’ 30 H
D4 High ‘0’ 30 H
Content of
address
2100H
PLC automatically convert ASCII codes to numerals and
store the numeral in D1296 = H0100
D5 Low ‘1’ 31 H
D5 High ‘7’ 37 H
D6 Low ‘6’ 36 H
D6 High ‘6’ 36 H
Content of
address
2101H
PLC automatically convert ASCII codes to numerals and
store the numeral in D1297 = H1766
D7 Low ‘0’ 30 H
D7 High ‘0’ 30 H
D8 Low ‘0’ 30 H
D8 High ‘0’ 30 H
Content of
address
2102H
PLC automatically convert ASCII codes to numerals and
store the numeral in D1298 = H0000
D9 Low ‘0’ 30 H
D9 High ‘0’ 30 H
D10 Low ‘0’ 30 H
D10 High ‘0’ 30 H
Content of
address
2103H
PLC automatically convert ASCII codes to numerals and
store the numeral in D1299 = H0000
D11 Low ‘0’ 30 H
D11 High ‘1’ 31 H
D12 Low ‘3’ 33 H
D12 High ‘6’ 36 H
Content of
address
2104H
PLC automatically convert ASCII codes to numerals and
store the numeral in D1300 = H0136
D13 Low ‘0’ 30 H
D13 High ‘0’ 30 H
D14 Low ‘0’ 30 H
D14 High ‘0’ 30 H
Content of
address
2105H
PLC automatically convert ASCII codes to numerals and
store the numeral in D1301 = H0000
D15 Low ‘3’ 33 H LRC CHK 1
D15 High ‘B’ 42 H LRC CHK 0
