Delta Electronics Programmable Logic Controller DVP-PLC User Manual
Page 401
7 Application Instructions API 50-99
D V P - P L C A P P L I C AT I O N M A N U A L
7 - 117
M1
PID
D10
D11
D0
GPWM
D20
Y0
END
D200
D0
The experiment result of auto-tuning:
Auto tuning area
S
3
+4 = k3
PID control area
S
3
+4 = k4
Auto tuning area
S
3
+4 = k3
PID control area
S
3
+4 = k4
The experiment result of using the adjusted parameter exclusively for temperature control after auto-tuning:
From the figure above, we can see that the temperature control after auto-tuning is working fine and we use only
