7 Application Instructions API 50-99

D V P - P L C A P P L I C AT I O N M A N U A L

7-114

1.5

1

0.5

0

0

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

1

PV=SV

K =10,K =8,K =0.2

P

I

D

Time (sec)

Note:

This example is only for your reference. Please adjust your parameters to proper ones according to your

actual condition of the control system.

Application Examples:

Application 1 Using PID instruction in the pressure control system (use the diagram of Example 1).

Purpose: Enabling the control system to reach the target pressure.

Explanation: The system requires a gradual control. Therefore, the system will be overloaded or out of control if the

process progresses too fast.

Suggested solution:

Solution 1: Longer sampling time

Solution 2: Using delay instruction. See the figure below.

PID

MV
D5

SV

PV

D1

D1110

0

511

0

511

0V

10V

0rpm

rpm

3000

D1116

0

255

0V

5V

A
wave

B
wave

pressure
meter

Pressure

instruction
value (D0)

Pressure

instruction

delay

MV

converted

to

speed

Voltage

converted

to

instruction

value

Speed

converted

to

voltage

AC

motor

drive

280

0

0

280

250

200

150

100

50

t

t

A wave

B wave

Instruction
value

Instruction
value

D2: Instruction interval value
D3: Instruction interval time
Adjusted by the user according to the actual condition
