SAN device properties
E
4. Click OK on the Properties dialog box to close.
Operational Status
The operational status of the product.
OS Type
The operating system.
Protocol
The LUN protocol.
Size (GB)
The total size of this LUN’s storage, in gigabytes.
State
The state of the LUN.
Storage LUN ID
The storage product’s LUN ID number for this LUN.
Storage Ports
The total number of storage ports assigned to the server or the port, or
bound to the LUN.
Type
The level or type of RAID storage. Possible values are as follows:
•
0. Striped disk array without fault tolerance.
•
1. Mirroring and duplexing.
•
2. Hamming code ECC.
•
3. Parallel transfer with parity.
•
4. Independent data disks with shared parity disk.
•
5. Independent data disks with distributed parity blocks.
•
6. Independent data disks with two independent distributed parity
schemes.
•
7. Optimized asynchrony for high I/O rates as well as high data
transfer rates.
•
10. Very high reliability combined with high performance.
•
53. High I/O rates and data transfer performance.
•
0+1. High data transfer performance.
Total (Count)
All LUNs, whether assigned or not, that currently exist on this storage
device.
Total (Size GB)
The total amount of storage space on the storage device, in gigabytes.
Unique LUN ID
Identifies the unique LUN identifier.
Volume State
The volume state of the LUN.
Add button
Click to add a user-defined property. For more information, refer to
Edit button
Click to edit a user-defined property. For more information, refer to
Delete button
Click to delete a user-defined property. For more information, refer to
Field
Description
