Names and Functions of Parts of the Control Panel
Chap
With the MKS-9011/9012 control
panel, you cannot directly control
DME5 to DME8.
When the [DEV] button is selected:
This
enables the VTR/disk recorder/frame
memory operation mode in the device
control block. Each button functions as
follows.
(From upper left to right in the above
figure)
[M/E1] to [M/E3]:
DEV1 (device 1) to
DEV3 (device 3)
[P/P]:
DEV4 (device 4)
[USER]:
FM1CLIP (frame memory
clip 1)
[Unused]:
FM2CLIP (frame memory
clip 2)
[DME1]:
DEV5 (device 5)
[DME2]:
DEV6 (device 6)
[Unused]:
DEV7 (device 7)
[Unused]:
DEV8 (device 8)
[Unused]:
FM LOOP (frame memory
loop)
[DME5] to [DME8]:
DEV9 (device 9)
to DEV12 (device 12)
To exit from this mode, press the
[DEV] button again, turning it off.
When the [RUN CTRL] button is
selected:
This enables the effect run
control mode in the device control
block.
When the [RSZR CTRL] button is
selected:
This enables the resizer
control mode in the device control
block.
For details on resizer, see page 196.
The functions of the operation buttons,
trackball, and Z-ring vary with the
operation mode as follows.
b
Operation buttons
When the positioner operation mode is
enabled
K1 CB1:
Press this button to enable wipe
pattern position setting for key 1
(DSK1).
When the [USER] button is selected,
pattern position setting for color
background 1 is enabled.
K2:
Press this button to enable wipe pattern
position setting for key 2 (DSK2).
K3:
Press this button to enable wipe pattern
position setting for key 3 (DSK3).
K4:
Press this button to enable wipe pattern
position setting for key 4 (DSK4).
WIPE:
Press this button to enable wipe
pattern position setting for normal
transitions.
Among the [K1 CB1] button, [K2] button,
[K3] button, [K4] button, and [WIPE]
button, you can select multiple buttons.
POS:
Press this button to enable pattern
movement in the x-axis and y-axis
directions with the trackball.
When the [USER] button is selected,
this enables the trackball to move the
pattern in the x-axis and y-axis
directions, and the Z-ring to adjust the
size of the pattern.
X, Y:
These restrict the axes affected by the
trackball and Z-ring to the x- or y-axis.
Z:
This restricts the axes affected by the
trackball and Z-ring to the z-axis.
CTR (center):
When this button is pressed,
the pattern position returns to the
center. When the [USER] button is
selected, the pattern size also returns to
50.00.
SHIFT/CLR WORK BUFR:
These are
not used in positioner operation mode.
When the three-dimensional transform
operation mode is enabled
The Buttons are used for three-dimensional
DME transformations.
