*Adjust this number to fit your particular configuration. Refer to the Application section in the display
User Manual for more information on adjusting this response threshold.
**If you are using a PWM control valve, some adjustment may need to be made to achieve optimal pump
response to the PWM gain value. Increase the Gain value to make the display more responsive;
decrease the Gain value to smooth the response.
L
IQUID
S
ERVO
S
ETTINGS
D
ESCRIPTION
• Valve Response 1
- Default Value: 100%
- Determines the speed of the servo valve when product control error exceeds the Response Threshold
setting.
- Decreasing the value will cause the servo valve to run slower.
• Valve Response 2
- Default Value: 24%
- Determines the speed of the servo valve when product control error is less than the Response
Threshold setting.
- Decreasing the value will cause the servo valve to run slower.
• Allowable Error
- Default Value: 2%
RoGator 1264,
1274 (up to
2006)
PWM Ground 122
**500-
700
30 2%
RoGator 1274,
1286 and SS
Series (2007
and up)
PWM Ground 122
**500-
700
30 2%
Spra-Coupe
3X40, 3X50,
4X40, 4X50
In-Line Servo 2% 100% 24% 3
Spra-Coupe
7000 with
factory pump
switch
PWM Ground 122
**500-
700
30 2%
Spra-Coupe
7000 without
factory pump
switch
PWM Ground 122
**500-
700
30 2%
TerraGator
XX03, XX04,
XX44
In-Line Servo 2% 40% 10% 15
Tyler Patriot,
Patriot II, XL,
150, 150XL and
WT
Check for In-Line
Servo or By-Pass
Servo Control
2% 100% 24% 3
Walker Pump Servo 2% 100% 24% 3
